JES 10 KVA

Category:

Description

JES Stabilizer Technical Specifications:
Model: SVC – 10 KVA
Brand: JES
Input Voltage: 140V ~ 250V
Output Voltage: 220V ± 2%
Phase: Single Phase
Indicator Display: Analog Voltmeter
Power: 10 KVA
Frequency: 50Hz/60Hz
Rated Current: 40A
Efficiency: More than 70%
Product Dimensions (PXLXT): 37 cm x 33 cm x 60 cm
Product Weight (Net): 49 kg
Product Weight (Gross): 52.4 kg
Working System: Fully Automatic
Control System: DC Servo Motor
Response Time: Within 0.5 sec. ~ 1 sec. against 10% input voltage deviation
Ambient Temperature: -5°C ~ +40°C
Ambient Humidity: Less than 90% (Relative Humidity)
Temperature Rise: Less than 80°C
Insulation Resistance: >2 MΩ
Wave Distortion: ≤1%
Output Voltage Accuracy: ±2%
Withstand Voltage: 2000 V/min
Isolation Resistance: >2 MΩ
Output Protection: 250V Automatic Cut-off
Package: Plywood Box
